12cavities Jar Preform Mold with Pnumatic Valve Gate System

Mould Specification: THE MATERIAL OF THE MOLD Mould cavity Germany 2316 with HRC 42-45Mould core Germany 2316 with HRC 45-48Mould neck Germany 2316 with HRC 45-50Valve PinSKD51 from Japan with HRC 58-60Valve Pin heat Isolation pad America Dupont can withstand 350 degre......Keywords:12cavities Jar Preform Mold with Pnumatic Valve Gate System, Mould, Mold

Product Description

Mould Specification:

THE MATERIAL OF THE MOLD
Mould cavity	Germany 2316 with HRC 42-45
Mould core	Germany 2316 with HRC 45-48
Mould neck	Germany 2316 with HRC 45-50
Valve Pin	SKD51 from Japan with HRC 58-60
Valve Pin heat Isolation pad	America Dupont can withstand 350 degrees temperature
Hot runner nozzle	America Beryllium copper with HRC 37
Mould manifold plate	H13 from America with HRC 35-38
Mould other plate	P20
Other Specification of the Mould
Hot runner system	Hot runner system is made by our own factory, But the spare parts of the Hot runner is from Germany Hotest
PID controller	Made by our own factory
Guarantee for the Mould	1 million shot times of 1 year
Free spare parts of the mould	Core set : 1set/ cavity: 1 Piece/ hot runner system:1set/PID controller system: 1Set/ other easy broken spare parts for each 8cavities preform mould.
The life of the mould	5-6years ,Even in 10 years in good maintenance
Installation & Commission	Our technician can be the buyer's factory to install and run the mould. But the buyer should bear all the cost for the technician's trip(include the air ticket, the cost of the accommodation and the salary)

CONDITIONS:
TERMS OF PRICE: FOB NINGBO PRICE.
TERMS OF PAYMENT:30%THE TOTAL AMOUNT IN ADVANCE BY T/T. 70%THE BANLANCE BY L/C AT SIGHT OR BY T/T AFTER TEST AND ACCEPT THE MAHCINE AND MOULD IN THE SELLER'S FACTORY..
THE DATE OF DELIEVERY: 35-45 DAYS AFTER GETTING THE DEPOSIT.
THE PORT OF DELIEVERY: NINGBO,CHINA
PACKING: EXPORT STANDARD PACKING
12cavities Jar Preform Mold with Pnumatic Valve Gate System

FAQ

Q: 1 Are you trading company or manufacturer ?

A: We are factory.

Q: 2 Where is your factory located?

A: Our factory is located in Huangyan, Taizhou city, Zhejiang Province, China.One hour from Taizhou airport by car, 15 minutes from train station to our factory.

Q: 3. How to go to your factory?

A: You can come to our city by flight, bus or train.
It takes 2 hours by flight from Guangzhou to our city.
It takes 3.5 hours by train from Shanghai to our city.
It takes 1 hour by bullet train from Ningbo to our city.

Q: 4.How about quality control in your factory?

A: We believe "Quality is above everything". We have professional team to control the quality. Our QC team mainly do the following procedures:
A) Design Optimize control
B) Mould steel hardness Inspection
C) Mould assembly Inspection
D) Mould trial report and samples Inspection
E) Final inspection for mould & packing before shipmentIf you have another question, pls feel free to contact us as below:

Q:5. If i provide you 3d drawing of my product, can you quote the price & make the mould as per the 3d drawing?

A:Yes.
DWG, DXF, STEP, IGS and X_T files can all be used to quote price, make mould as per your models - This can save time and money in producing your parts.

Q: 6. What type of plastic material is best for my design/component?

A: Plastic Materials selection depends on the application of your product. We will give you some suggestion after we checked the function of your component. And we can make the mould trial with different material according to your requirement.

Q: 7. What kind of mould can you make?

A: We can make all kinds of plastic injection moulds and blow moulds.
We can suggest you the proper cavity number as per your injection machines sizes.
